瞬态抑制二极管
按条件查询:

Uni

SMF5.0A

SMDJ5.0A

SMCJ5.0A

SMBJ 5.0A

SMAJ 5.0A

SM8S18A

SM6S 18A

SM4F5.0A

P6SMB6.8A

P6SMAJ5.0A

P6KE6.8A

P4SMA36A

P4KE6.8A

HP3KA-30CL

30KPA28A

20KP17A

15KP17A

8.0SMDJ 11A

5KP28A

5KP5.0A

5.0SMDJ11A

3.0SMBJ12A

1.5SMC6.8A

1.0SMB6.8A

1.5KE7.5A

Bi

SMF5.0CA

SMDJ5.0CA

SMCJ5.0CA

SMBJ 5.0CA

SMAJ 5.0CA

SM8S18CA

SM6S 18CA

SM4F5.0CA

P6SMB6.8CA

P6SMAJ5.0CA

P6KE6.8CA

P4SMA36CA

P4KE6.8CA

D16

30KPA28CA

20KP17CA

15KP17CA

8.0SMDJ 11CA

5KP28CA

5KP5.0CA

5.0SMDJ11CA

3.0SMBJ12CA

1.5SMC6.8CA

1.0SMB6.8CA

1.5KE7.5CA

VR(V)

5

5.0

18.0

5.80

30.80

28.0

17.0

11.0

12.0

5.8

Min(V)

6.4

6.40

20.00

6.45

34.20

31.28

18.99

12.20

31.10

13.30

Max(V)

7

7.00

22.10

7.14

37.80

34.57

21.22

13.50

34.40

14.70

IT(mA)

10

5

1

50

VC(V)

9.2

29.2

10.5

49.9

100

50.0

31.0

29.3

18.2

45.4

19.9

IPP(A)

21.8

326.1

163.0

65.3

43.5

226.0

158.0

43.6

58.1

8.2

39.0

606.0

645.1

515.4

440.0

112.3

554.3

275.0

150.8

144.8

96.8

IR(μA

500

600

800

2

1000

1

5

2500

2000

产品查询结果:
UniBiVR(V)Min(V)Max(V)IT(mA)VC(V)IPP(A)IR(μA Specification
SMF5.0A SMF5.0CA 5 6.4 7 10 9.2 21.8 500 产品规格书 样片与订购
SMDJ5.0A SMDJ5.0CA 5.0 6.40 7.00 10 9.2 326.1 600 产品规格书 样片与订购
SMCJ5.0A SMCJ5.0CA 5.0 6.40 7.00 10 9.2 163.0 800 产品规格书 样片与订购
SMBJ 5.0A SMBJ 5.0CA 5.0 6.40 7.00 10 9.2 65.3 800 产品规格书 样片与订购
SMAJ 5.0A SMAJ 5.0CA 5.0 6.40 7.00 10 9.2 43.5 800 产品规格书 样片与订购
SM8S18A SM8S18CA 18.0 20.00 22.10 5 29.2 226.0 2 产品规格书 样片与订购
SM6S 18A SM6S 18CA 18.0 20.00 22.10 5 29.2 158.0 2 产品规格书 样片与订购
SM4F5.0A SM4F5.0CA 5 6.4 7 10 9.2 43.6 500 产品规格书 样片与订购
P6SMB6.8A P6SMB6.8CA 5.80 6.45 7.14 10 10.5 58.1 1000 产品规格书 样片与订购
P6SMAJ5.0A P6SMAJ5.0CA 5.0 6.40 7.00 10 9.2 65.3 800 产品规格书 样片与订购
P6KE6.8A P6KE6.8CA 5.80 6.45 7.14 10 10.5 58.1 1000 产品规格书 样片与订购
P4SMA36A P4SMA36CA 30.80 34.20 37.80 1 49.9 8.2 1 产品规格书 样片与订购
P4KE6.8A P4KE6.8CA 5.80 6.45 7.14 10 10.5 39.0 1000 产品规格书 样片与订购
HP3KA-30CL D16 1 100 5 产品规格书 样片与订购
HP3KA-30CL 5 产品规格书 样片与订购
30KPA28A 30KPA28CA 28.0 31.28 34.57 50 50.0 606.0 2500 产品规格书 样片与订购
20KP17A 20KP17CA 17.0 18.99 21.22 50 31.0 645.1 2000 产品规格书 样片与订购
15KP17A 15KP17CA 17.0 18.99 21.22 50 29.3 515.4 2000 产品规格书 样片与订购
8.0SMDJ 11A 8.0SMDJ 11CA 11.0 12.20 13.50 10 18.2 440.0 800 产品规格书 样片与订购
5KP28A 5KP28CA 28.0 31.10 34.40 5 45.4 112.3 2 产品规格书 样片与订购
5KP5.0A 5KP5.0CA 5.0 6.4 7.00 50 9.2 554.3 2000 产品规格书 样片与订购
5.0SMDJ11A 5.0SMDJ11CA 11.0 12.20 13.50 10 18.2 275.0 800 产品规格书 样片与订购
3.0SMBJ12A 3.0SMBJ12CA 12.0 13.30 14.70 1 19.9 150.8 600 产品规格书 样片与订购
1.5SMC6.8A 1.5SMC6.8CA 5.8 6.45 7.14 10 10.5 144.8 1000 产品规格书 样片与订购
1.0SMB6.8A 1.0SMB6.8CA 5.8 6.45 7.14 10 10.5 96.8 1000 产品规格书 样片与订购
1.5KE7.5A 1.5KE7.5CA 5.8 6.45 7.14 10 10.5 144.8 1000 产品规格书 样片与订购
